DP Intel 10U System with NVIDIA HGX B200 8-GPU.
Official Supermicro specifications for the SYS-A22GA-NBRT.
| Model | Super X14DBG-DAP |
|---|
| CPU | Dual Socket BR (LGA-7529) Intel® Xeon® 6900 series processors with P-cores |
|---|---|
| Core Count | Up to 128C/256T; Up to 504MB Cache per CPU |
| Max GPU Count | 8 onboard GPUs |
|---|---|
| Supported GPU | NVIDIA SXM: HGX B200 8-GPU (180GB) — 1.4TB GPU memory space |
| CPU-GPU Interconnect | PCIe 5.0 x16 CPU-to-GPU Interconnect |
| GPU-GPU Interconnect | NVIDIA® NVLink™ with NVSwitch™ |
| Memory | Slot Count: 24 DIMM slots Max Memory (1DPC): Up to 6TB 6400MT/s ECC DDR5 RDIMM Max Memory (1DPC): Up to 6TB 8800MT/s ECC DDR5 MRDIMM |
|---|
| Network Connectivity | 2 RJ45 10GbE with Intel® X710 |
|---|
| LAN | 1 RJ45 1GbE Dedicated BMC LAN port |
|---|---|
| USB | 2 USB 3.0 ports (rear) |
| Video | 1 VGA port |
| TPM | 1 TPM header |
| BIOS Type | AMI 64MB UEFI |
|---|
| Software | SuperCloud Composer®; Supermicro Server Manager (SSM); Super Diagnostics Offline (SDO); Supermicro Thin-Agent Service (TAS); SuperServer Automation Assistant (SAA) |
|---|
| CPU | Monitors for CPU Cores, Chipset & Memory voltages |
|---|---|
| FAN | Fans with tachometer monitoring; PWM fan connectors with speed control |
| Temperature | Monitoring for CPU and chassis environment; thermal control for fan connectors |
| Form Factor | 10U Rackmount |
|---|---|
| Model | CSE-GP1001TS-R000NPF |
| Enclosure | 449 x 438.8 x 843.28 mm (17.6" x 17.2" x 33.2") |
|---|---|
| Package | 730 x 710 x 1280 mm (28.74" x 27.95" x 50.39") |
| Weight | Gross Weight: 341 lbs (155 kg) Net Weight: 293 lbs (133 kg) |
| Available Color | Silver |
| PCI-Express (PCIe) Configuration | Default: 10 PCIe 5.0 x16 LP slots + 2 PCIe 5.0 x16 FHHL slots |
|---|
| Drive Bays Configuration | Default: Total 10 bays — 10 front hot-swap 2.5" PCIe 5.0 x4 NVMe |
|---|---|
| M.2 | 2 M.2 PCIe 4.0 x4 NVMe slots (M-key 2280/22110; RAID support via S3808N controller) |
| Fans | Up to 15 counter-rotating 80x80x80mm fans + up to 4 counter-rotating 60x60x56mm fans |
|---|---|
| Air Shroud | 1 Air Shroud |
| Environmental Spec. | Operating Temperature: 10°C to 35°C (50°F to 95°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) |
|---|
| PSU | 6x 5250W Redundant (3 + 3) Titanium Level (96%) |
|---|
